Molybdenum Wire Mesh
Molybdenum Wire Mesh is a type of woven wire mesh which is made of pure molybdenum wires or alloy wires. According to the weaving patterns molybdenum wire mesh has plain weave twill weave dutch weave patterns with square and rectangular shaped holes on surface.
Molybdenum wire mesh has high strength and low elongation excellent electric-conductivity heat-conducting property. It can also resist corrosion acid alkaline oxidation and other harsh environment. Molybdenum wire mesh can be popularly used in high-temperature field such as furnace petroleum chemical food medicine machinery and other industries for filtering and sieving use. Molybdenum wire mesh has heat-conductivity and corrosion resistance.
Features of Molybdenum Wire Mesh
- High tensile strength.
- Low elongation.
- Acid and alkaline resistant.
- Corrosion resistant.
- High temperature resistant.
- Good electricity-conductivity.
- Lightweight.
- Various hole shapes.
- Excellent filtering performance.
Technical Details
- Name: Molybdenum wire mesh Molybdenum mesh
- Material: Pure molybdenum wire molybdenum alloy wire
- Mesh Count: 1-300 Parts are in stock
- Melting point: 2610°C - 2640°C.
- Weaving: Plain weave twill weave dutch weave
Specification of Molybdenum Wire Mesh
| Mesh/Inch |
Wire Diameter (mm) |
Opening (mm) |
Opening Area % |
Weight kg/m2 |
Mesh/Inch |
Wire Diameter (mm) |
Opening (mm) |
Opening Area % |
Weight kg/m2 |
| 1 |
4.87 |
20.523 |
68% |
15.40 |
40 |
0.25 |
0.385 |
37% |
1.62 |
| 2 |
3.04 |
9.652 |
58% |
12.00 |
40 |
0.23 |
0.401 |
40% |
1.37 |
| 2 |
2.60 |
10.033 |
62% |
8.78 |
40 |
0.22 |
0.415 |
43% |
1.25 |
| 3 |
2.00 |
6.467 |
58% |
7.80 |
40 |
0.19 |
0.445 |
49% |
0.93 |
| 3 |
1.60 |
6.867 |
66% |
4.99 |
50 |
0.19 |
0.318 |
39% |
1.17 |
| 4 |
1.60 |
4.750 |
56% |
6.65 |
50 |
0.15 |
0.335 |
49% |
0.73 |
| 4 |
1.20 |
5.150 |
66% |
3.74 |
50 |
0.20 |
0.478 |
89% |
1.29 |
| 5 |
1.20 |
3.880 |
58% |
4.67 |
60 |
0.15 |
0.273 |
42% |
0.87 |
| 5 |
1.00 |
4.080 |
65% |
3.24 |
60 |
0.16 |
0.263 |
39% |
0.99 |
| 6 |
1.20 |
3.033 |
51% |
5.61 |
70 |
0.12 |
0.243 |
45% |
0.65 |
| 6 |
0.90 |
3.333 |
62% |
3.15 |
80 |
0.12 |
0.198 |
39% |
0.74 |
| 8 |
0.61 |
2.565 |
65% |
1.93 |
90 |
0.12 |
0.162 |
33% |
0.84 |
| 10 |
0.50 |
2.032 |
64% |
1.62 |
100 |
0.10 |
0.154 |
37% |
0.64 |
| 10 |
0.45 |
2.083 |
67% |
1.31 |
100 |
0.076 |
0.177 |
49% |
0.37 |
| 12 |
0.50 |
1.609 |
58% |
1.94 |
120 |
0.09 |
0.122 |
33% |
0.63 |
| 14 |
0.42 |
1.397 |
59% |
1.60 |
120 |
0.08 |
0.132 |
39% |
0.49 |
| 16 |
0.38 |
1.212 |
58% |
1.50 |
140 |
0.06 |
0.121 |
45% |
0.32 |
| 18 |
0.28 |
1.317 |
65% |
0.91 |
150 |
0.065 |
0.104 |
38% |
0.41 |
| 20 |
0.40 |
0.870 |
47% |
2.07 |
180 |
0.06 |
0.081 |
33% |
0.42 |
| 20 |
0.32 |
0.955 |
57% |
1.33 |
180 |
0.05 |
0.091 |
42% |
0.29 |
| 24 |
0.28 |
0.784 |
55% |
1.22 |
200 |
0.05 |
0.077 |
37% |
0.32 |
| 24 |
0.23 |
0.824 |
61% |
0.82 |
250 |
0.04 |
0.062 |
37% |
0.25 |
| 26 |
0.25 |
0.723 |
55% |
1.32 |
270 |
0.028 |
0.066 |
49% |
0.13 |
| 28 |
0.27 |
0.633 |
49% |
1.32 |
280 |
0.03 |
0.061 |
45% |
0.16 |
| 28 |
0.23 |
0.673 |
55% |
0.96 |
300 |
0.04 |
0.045 |
28% |
0.31 |
| 30 |
0.23 |
0.613 |
52% |
1.03 |
325 |
0.035 |
0.043 |
30% |
0.25 |
| 32 |
0.30 |
0.494 |
39% |
1.87 |
400 |
0.038 |
0.038 |
37% |
0.16 |
Note: Special size and specifications can be made according to customers requires.
Chemical Composition of Molybdenum Wire Mesh
| C |
Fe |
Ni |
O |
Si |
N |
Mo |
| 0.01 |
0.01 |
0.005 |
0.007 |
0.01 |
0.02 |
Rem |
|
